Carbon Offroad CW-XD15YEL Carbon Scout Pro - 15000lb Winch V3 - YELLOW

SKU:CW-XD15YEL

$1,299.00


Calculate Shipping

Carbon Offroad Scout Pro 15K Winch—15,000lb pulling power bridging 12K and truck-grade 20K units. Features a 7.0HP motor, 11mm UHMWPE rope, forged thimble, MegaPro hook, premium fairlead, and wired/wireless remotes. Built tough for heavy rigs and extreme off-road recoveries.

Technical Features

  • Part number: CW-XD15-V3
  • Rated line pull: 15000 lbs, (6803kg) single-line
  • Motor: 12V DC 7 HP series wound motor (24V option available)
  • Remote Control: Wired with 3.6m lead
  • Wireless Remote Control: Included
  • Geartrain: 3-Stage Planetary
  • Gear Ratio: 218:1
  • Rotating Ring Gear
  • Brake: Automatic brake in the motor bracket
  • Fairlead: Carbon Offroad MEGAPRO Premium CNC billet type 3 hard anodised multi position fairlead
  • Lifetime Mechanical Warranty
  • 5 Year Electrical Warranty
  • 5 Year Water Ingress Protection Warranty
  • Synthetic Rope: 24m x 11mm diameter
  • Drum Diameter/Length: 63.5mm x 224mm
  • Mounting Bolt Pattern: 254mm x 114.3mm
  • Recommended Battery: 650 CCA minimum for winching
  • Winch Dimensions (L x W x H): 556.5 x 158 x 187mm
  • Packing Dimensions (L x W x H): 580 x 200 x 220mm
  • Winch weight including synthetic rope, control box complete with cables, mounting bolts & fairlead: 26.7

Speed & Performance Breakdown

12V DC Performance Specs

Line Pull lbs (kgs) Line Speed ft/min (m/min) Motor Current (Amps) Rated Line Pull Position lbs (kgs)
0 27.9(8.5) 65 1/15000(6810)
2000(910) 11.8(3.6) 120 2/12700(5765)
6000(2720) 9.5(2.9) 160 3/10770(4890)
10000(4540) 6.6(2.0) 215 4/9130(4145)
13000(5900) 4.6(1.4) 265 -
15000(6818) 3.6(1.1) 380 -
SKU CW-XD15YEL
Brand CARBON OFFROAD
