Carbon Offroad CW-RS9-S-SAN Carbon Offroad - RS9-S 9000lb Short Drum - SANDY TAUPE

SKU:CW-RS9-S-SAN

$1,549.00


Calculate Shipping

The Carbon Offroad Scout Pro RS Series winches are built with racing and high speed in mind.

With larger modulus gearsets, increased motor horsepower and standard inclusions from our premium accessory range including the Mega-Pro Winch Rope Thimble and Mega-Pro Premium Fairlead, you are getting a best of the best package straight out of the box.

The RS series winches share the same 2023 Version 3 Winch Chassis as our tried and tested 12K winch. Due to the longer 8.0HP Motor, you should consult the technical drawing to determine clearance and fitment length on your winch mount.  The responsibility of the fitment is that of the end-user or installer.

The RS9 9000lb winch comes with 8mm high density pre stretched premium UHMWPE winch rope rated at a whopping 14000lb minimum breaking strain.

  • Carbon Winch Shortend 2023 V3 winch chassis
  • 8.0HP Motor
  • 80:1 heavy duty performance gearbox
  • 8mm x 24m Synthetic Rope with HD braced rope thimble

Technical Features

  • Rated line pull: 9,000lb (4,080kg)
  • Voltage: 12V
  • Motor: 8.0HP
  • Gear ratio: 80:1
  • Sealing: IP68 water/dust sealed
  • Rope: 8mm x 24m (5/16in x 80ft) Spectra fibre synthetic rope
  • Mounting bolt pattern: 164 x 114.3mm (6.46in x 4.5in)
  • Drum diameter x length: 63 x 122mm (2in x 4.8in)
  • Winch dimensions (L x W x H): 385 x 115 x 120mm (15.16in x 4.53in x 4.7in)
SKU CW-RS9-S-SAN
Brand CARBON OFFROAD
