Redarc Handbrake Alarm Audio & Visual Warning System HBA1224

SKU:HBA1224

$249.00


Calculate Shipping

The HBA1224 alarm is used in a 12V or 24V automotive system.

It monitors the handbrake switch and the doorframe switch* to provide audible and visual warning if the door is opened while the handbrake is not applied.

Once the alarm starts, it stays latched on until the handbrake is applied (even if the door is closed again).

Three connector options availableThe standard HBA1224 features a fly lead, while the HBA1224-003 features a male connector lead 10 way (9 wire) for a faster, simpler installation.HBA1224: Standard (no) ConnectorHBA1224-003: Connectorised LoomThe HBA1224 improves vehicle safety as it:Reduces the risk of the vehicle being accidentally left unattended without the handbrake on.

If used with external relay/horn, it can provide a warning to anyone in the general area, that a vehicle has been left without its handbrake on.

Hummingbird Electronics offer an optional external Compact Combination Warning LED and Buzzer which is perfectly suited for REDARCs Hand Brake Alarm.

Available in both 12 and 24 volt variants.

BenefitsWarns you when you forget to apply the handbrakeSecurity against damage caused by runaway vehiclesHorn output ensures others will be warnedA mandatory health and safety installation on many mining site vehicles FeaturesBuilt-in LED warning light and internal piezo buzzer plus external outputDesigned for universal fitmentOutput latches on once triggeredCan be used in various other installations (headlight alarm)*The doorframe switch is the switch mounted in the doorframe that switches on the cab light when the door is opened.

brandREDARC
Alarm TypeAudio (sound / alarm), Visual (lights)
Standby Current<2mA
Weight40 g
height30 mm
width25 mm
depth | length50 mm
Warranty2 Years
operating voltage9 - 32V DC
SKU HBA1224
Barcode # 9338628000548
Brand REDARC
