STEDI Type-X™ Pro Plus Non-DRL Modern Classic Pair PRP-MDRNCLASS-NDRL-BND

SKU:PRP-MDRNCLASS-NDRL-BND

$839.00


Calculate Shipping

What's Included

  • Base Driving Lights
    2 x Type-X™ Pro Plus Non-DRL Module
  • Bezel
    2 x Type-X™ Pro Plus Bezel Modern
  • Fascia
    2 x Type-X™ Pro Plus Modern Ring Grey
  • Covers
    2 x Type-X™ Pro Plus Modern Classic Cover STEDI
  • Shoulder Trim
    2 x Type-X™ Pro Plus Shoulder Trim Modern Grey
  • High Beam Triggered Wiring Harness
    1 x Dual Connector Plug & Play SMART Harness™ High Beam Driving Light Wiring
  • Pro Plus Packaging
    1 x Pro Plus Custom Spec Box
    1 x Pro Plus Custom Spec Shipping Carton

MINIMALISM REFINED.
The Modern Classic option in the Type-X™ PRO PLUS range represents the pinnacle of sleek, minimalist design. Elevating the refined aesthetic of the Modern option, this configuration introduces a sophisticated cover for a streamlined, elegant appearance. Clean lines and timeless simplicity define the Modern Classic, delivering a contemporary look where minimalism takes centre stage.

CURATED SIMPLICITY.
This configuration features the modern bezel, paired with a meticulously refined cover that enhances its slim profile. The array of modern fascias, available in 9 stunning colourways, along with optional shoulder trims, allows for subtle personalisation without compromising the understated design. Every detail has been carefully curated to deliver a polished aesthetic while maintaining the durability Type-X™ lights are known for.

PERFORMANCE WITHOUT COMPROMISE.
The Modern Classic non-DRL variant delivers exceptional lighting performance with a 1 LUX distance of 1360m. Whether you’re navigating urban streets or venturing into rugged environments, it provides outstanding visibility, reliability, and style for those who demand both form and function.

Tech Specs

Non-DRL

LED 33x CREE XP20 + 12x CREE XPP
RAW LUMENS     18,280 lm (each)
TESTED LUMENS 14,893 lm (each) | 30,922 lm (Pair)
AMP DRAW 7.92A @ 24V (each)
POWER DRAW 190W (each)
CANDELA 976,000 cd (Single) | 1,952,000 cd (Pair)
BEAM PATTERN Combo(36 Spot + 9 Flood)
INGRESS PROTECTION IP68 | Submersible up to 3m
COLOUR TEMP (CCT) 5000K
VOLTAGE COMPATIBILITY 10v - 30v
LUMEN MAINTENANCE 50,000 LM-80
WEIGHT 3.2kg (each)
OPERATING TEMP -40°C - 60°C
990m 1 LX (Single)
1634m 1 LX (Pair)
SKU PRP-MDRNCLASS-NDRL-BND
Brand STEDI
