What's Included
- Base Driving Light
2 x Type-X™ Pro Plus DRL Module - Bezel
2 x Type-X™ Pro Plus Bezel Rugged - Fascia
2 x Type-X™ Pro Plus Rugged Ring Orange - Covers
2 x Type-X™ Pro Plus Rugged DRL Cover STEDI - Shoulder Trim
2 x Type-X™ Pro Plus Shoulder Trim Rugged Orange - High Beam Triggered Wiring Harness
1 x Dual Connector DT-4 Plug & Play SMART Harness™ High Beam Driving Light Wiring - Pro Plus Packaging
1 x Pro Plus Custom Spec Box
1 x Pro Plus Custom Spec Shipping Carton
PAYING HOMAGE TO THE CLASSIC.
The Rugged option in the Type-X™ PRO PLUS range pays homage to the classic Type-X™ PRO series, retaining its bold and dependable aesthetic. This style blends the timeless design of the original with the cutting-edge features of the PRO PLUS, making it a perfect choice for those who value tradition without sacrificing innovation.
TIMELESS DESIGN.
Key components of the Type-X™ PRO PLUS Rugged style include the rugged bezel, rugged fascia (available in up to 9 colourways), and rugged covers in both DRL and non-DRL variants. Optional shoulder trim accents provide further customisation, ensuring your driving lights deliver not only durability but also a tailored aesthetic to match your vehicle’s style.
UNPARALLELED PERFORMANCE.
Type-X™ PRO PLUS (pair) will throw light over 1.5km down the road with precision, with 12 dedicated flood reflectors illuminating the critical zones of the road, resulting in an incredibly smooth driving beam. Rendering a beautiful 5000K colour temperature, you’ll experience the ideal balance between clarity and definition, allowing your eyes to process details like obstacles and terrain with ease.
Tech Specs
|
OPTICAL BEAM (DRL) |
Combo Beam (36x Spot | 9x Flood | 4x DRL) |
|
TESTED LUMENS (DRL) |
29,664lm (Pair) |
|
1 LUX @ (DRL) |
1540 Metres (Pair) |
|
CANDELA (DRL) |
1,846,240cd (Pair) |
|
AMP DRAW (DRL) |
7.98A @ 24V |
|
INGRESS PROTECTION |
IP68 | Submersible up to 3m |
|
COLOUR TEMP (CCT) |
5000 Kelvin |
|
VOLTAGE COMPATIBILITY |
10 - 30V DC |
|
WEIGHT (EACH – DRL) |
3.65kg (Each) |
|
OPERATING VOLTAGE |
-40°C to 60°C |
| SKU | PRP-RUGGED-DRL-BND |
| Brand | STEDI |
