What's Included
- Base Driving Light
- 2 x Type-X™ Pro Plus DRL Module
- Bezel
- 2 x Type-X™ Pro Plus Bezel Modern
- Fascia
- 2 x Type-X™ Pro Plus Modern Rugged Ring Yellow
- Covers
2 x Type-X™ Pro Plus Modern Rugged DRL Cover STEDI - Shoulder Trim
2 x Type-X™ Pro Plus Shoulder Trim Rugged Yellow - High Beam Triggered Wiring Harness
1 x Dual Connector DT-4 Plug & Play SMART Harness™ High Beam Driving Light Wiring - Pro Plus Packaging
1 x Pro Plus Custom Spec Box
1 x Pro Plus Custom Spec Shipping Carton
WHERE CLASSIC MEETS CONTEMPORARY.
The Type-X™ PRO PLUS Modern Rugged series strikes the perfect balance between timeless design and contemporary innovation. It fuses elements of the classic Type-X™ PRO design with modern curves and bold accents, creating a versatile look that’s both tough and sophisticated.
BOLDLY CUSTOMISABLE.
The Type-X™ PRO PLUS Modern Rugged variant features the modern rugged bezel, paired with modern rugged fascia available in 9 vibrant colourways and matching covers. Optional shoulder trims also available in 9 colourways allow you to fine-tune the look even further, delivering a bold, tailored finish that complements a wide range of vehicles.
BUILT FOR THE ROAD AHEAD.
Type-X™ PRO PLUS (pair) will throw light over 1.5km down the road with precision, with 12 dedicated flood reflectors illuminating the critical zones of the road, resulting in an incredibly smooth driving beam. Rendering a beautiful 5000K colour temperature, you’ll experience the ideal balance between clarity and definition, allowing your eyes to process details like obstacles and terrain with ease.
Tech Specs
|
OPTICAL BEAM (DRL) |
Combo Beam (36x Spot | 9x Flood | 4x DRL) |
|
TESTED LUMENS (DRL) |
29,664lm (Pair) |
|
1 LUX @ (DRL) |
1540 Metres (Pair) |
|
CANDELA (DRL) |
1,846,240cd (Pair) |
|
AMP DRAW (DRL) |
7.98A @ 24V |
|
INGRESS PROTECTION |
IP68 | Submersible up to 3m |
|
COLOUR TEMP (CCT) |
5000 Kelvin |
|
VOLTAGE COMPATIBILITY |
10 - 30V DC |
|
WEIGHT (EACH – DRL) |
3.65kg (Each) |
|
OPERATING VOLTAGE |
-40°C to 60°C |
| SKU | PRP-MDRNRGD-DRL-BND |
| Brand | STEDI |
