DNA Audio CBA030M Short Stop Auto Reset Thermal Circuit Breaker - 30 Amp

SKU:CBA030M

$15.95


Calculate Shipping

Short Stop Auto Reset Thermal Circuit Breaker - 30 Amp

This single pole thermal type circuit breaker is perfect for installation applications with battery chargers, cars, trucks, buses, RVs, trolling motors, etc
Available as an option is the CBA050C rubber cover which is designed to fit this circuit breaker

Reset: Auto reset
Voltage Range: 12 VDC~24 VDC
Rated Current: 30 Amps
Pole Count: 1 Pole
Termination: 2 x #10-32 UNF thread terminals. (Copper terminal for connection to battery. Silver terminal for connection to aux device)
Body Material: Metal
Cover Material: Black thermoplastic cover
Mounting Type: 90° Chassis mount 49mm long metal bracket with 2 mounting holes (40mm hole centre to hole centre)
Size: 32mm L x 20mm W x 33mm H
Packaging: Poly bag with barcode sticker

SKU CBA030M
Brand DNA DESIGNER AUDIO
