AUDIO CONTROL

AudioControl PNW Series 3-Way Crossover Network

SKU:PNW-XN3

RRP $399.00
$359.00
SAVE $40.00 (10%)


Calculate Shipping

PNW Series - 3-way crossover network

Easily create a 3-way speaker system by adding PNW-275 to either PNW-65CS2 or PNW-69CS2. Configurable from 2, 4 or 6 channels of input.

Features

  • 2nd Order Linkwitz-Riley Crossover Slope with Zobel Networks
  • 350 Hz LP (PNW-65/PNW-69), 350 Hz to 4 kHz BP (PNW-275), 4 kHz HP (PNW-1)
  • 150 Watts RMS

Specifications

Crossover Type                                       2nd order Linkwitz-Riley

Filter Type                                                HP / BP / LP

XO Frequency                                         350Hz LP / 350-4k BP / 4K HP

Slope (Octave)                                         -12 dB

Power Handling (RMS/Max)                 150 Watts / 200 Watts

Attenuation (Tw / Md)                           0 / -3 / -6 dB

Recommended Speaker Set 1             PNW-65CS2 + PNW-275

Recommended Speaker Set 2             PNW-69CS2 + PNW-275

In The Box:

PNW-XN3, Manual, Warranty

Dimensions

  • Length: 10.6 in / 270 mm
  • Width: 5.12 in / 130 mm
  • Height: 1.13 in / 28.6 mm

Specifications

Manufacturer Part NumberPNW-XN3
Compatible ProductsPNW-275, PNW-65CS2, PNW-69CS2
SKU PNW-XN3
Barcode # 850038647537
Brand AUDIO CONTROL
