Aerpro AMDVW5 10 Inch Multimedia Receiver To Suit Various Volkswagen Models - With Factory Mib-pq Unit

The Aerpro AMDVW5 10" Multimedia Receiver with Wireless Apple CarPlay, Android Auto and DAB+ suits Volkswagen Amarok (2016-on), Beetle (2015-2016), Caddy (2015-2020), Multivan (2016-2019), Tiguan (2015-2016)*, Transporter (2016-2019) vehicles (with factory MIB-PQ unit). Featuring a large 10" capacitive touchscreen display with a crisp 1024x600 resolution, this Multimedia Receiver has Apple CarPlay and Android Auto which can be used wireless or wired, built-in Bluetooth V5 for hands-free phone calls & wireless audio streaming, dual rear USB inputs, built-in DAB+ digital radio for crystal-clear sound and a wider range of stations, as well as an AM/FM radio tuner. Sound quality is superb with 50Wx4 max output, 13-band graphic EQ and time alignment capabilities, amplifiers can be added to the system via the 4V/5CH RCA preouts. Supplied as a complete Head Unit Upgrade Kit, the Aerpro AMDVW5 includes all the parts required to complete the installation and retains important vehicle features including steering wheel controls, factory amplified system, parking tones and access to the vehicle menu. A Surface Mount Camera is also included, delivering clear picture quality with a 110 degree field of view, optional parking guidelines and IP67 rating.

Important Information:

• Head Unit Upgrade Kits can vary between vehicle models, please use the Aerpro What Fits Your Car Guide to find the correct parts.
• This kit includes an Infodaptor Interface which allows vehicle information to be displayed & accessed on the aftermarket head unit, retains steering wheel controls, retains parking tones & amplified system. The Interface connects to the rear camera input on the aftermarket head unit and the output for this kit will be low resolution.
• Only suits vehicles with MIB-PQ unit from factory.
• (*) Due to the size of the head unit, please be aware in Tiguan (2015-2016) vehicles the kit partially covers hazard button.
• Ignition Stabiliser may be required for stop-start models (Aerpro APIGNSTB, not included).
• Camera retention adaptor required to retain factory camera (Aerpro APVVW03, not included).
• May need to remove fuse from factory Bluetooth module for phone button to work.
• This head unit is sold as a kit which includes:
  • AM1005D Multimedia Receiver
  • Matte Black Facia Kit
  • Infodaptor Interface Harness
  • SWC Patch Lead
  • Antenna Adaptor
  • Universal Rear Camera

Features

• Complete Head Unit Upgrade Kit: Includes all the parts required to complete the installation and retain important vehicle features for Various Volkswagen Models - with Factory Mib-Pq Unit.
• Vehicle Feature Retention: Retains steering wheel controls, factory reverse camera, parking tones and vehicle menu.
• Large 10" Capacitive Touchscreen Display: Crisp 1024x600 resolution with smooth, responsive control for easy navigation of maps, media, and menus.
• Wireless Apple CarPlay & Android Auto: Instantly access maps, music, calls, and messages without plugging in your phone, or connect via USB for wired operation and charging.
• Built-In DAB+ Digital Radio: Enjoy crystal-clear digital sound quality and a wider range of stations, plus AM/FM tuning with RDS for all your broadcast preferences.
• Bluetooth Hands-Free Calling & Audio Streaming: Bluetooth V5 with HD Voice support, internal and external microphone options, and full phonebook and audio streaming capability.
• USB Media Playback Support: Play music, videos, and photos directly from a USB drive in popular file formats.
• Surface Mount Camera Included: Clear picture quality with a 110 degree field of view, optional parking guidelines and IP67 rating — mountable as a front, rear or reverse camera.
• High-Power Audio with Advanced Tuning: 4 x 50W Max output, 5-channel 4V RCA preouts, 13-band EQ, time alignment, and subwoofer control for clear, powerful sound.
• Multi-Colour Key Illumination: Customisable 6-colour button lighting to match your vehicle's interior.

Specs

AMDVW5 HEAD UNIT UPGRADE KIT SPECIFICATIONS:

• Kit Inclusions:
  • AM1005D Multimedia Receiver
  • Matte Black Facia Kit
  • Infolink Steering Control Interface Harness
  • SWC Patch Lead
  • Antenna Adaptor
  • Universal Rear Camera
• Vehicle Feature Retention:
  • Steering Wheel Controls: Yes
  • Factory Reverse Camera: Yes (Aerpro APVVW03 required, not included).
  • AUX Input: N/A
  • USB Input: N/A
  • Parking Tones: Yes
  • Factory Amplifier: Yes
  • Vehicle Menu: Yes
  • Other: N/A

AM1005D MULTIMEDIA RECEIVER SPECIFICATIONS:

• LCD Display:
  • Size: 10"
  • Resolution: 1024x600
  • Touch Screen: Capacitive
• OS System: Linux
• DIN Size: Fixed Screen Style (Trapezoid)
• Power Output:
  • MAX Power (4 Ohm): 4CH x 50W
• Media Playback: MP3 / MP4 / MKV / FLAC / Xvid
• Device Ports:
  • USB1 (Rear): Apple CarPlay & Android Auto with Charging Function – 5V / 1.5A
  • USB2 (Rear): Media with Charging Function – 5V / 1.5A
  • USB MAX Capability: FAT32_32GB
• Aux Inputs / Outputs:
  • Rear A/V Input (RCA Type – 3pcs): Yes
  • Composite Video Output: Yes (Two)
  • Reverse Camera Input: Yes (720P AHD Compatible)
  • Second Camera Input: Yes (720P AHD Compatible)
• Smartphone Connectivity: CarPlay & Android Auto (Wireless and Wired)
• Bluetooth:
  • Bluetooth Built-In: Yes (A2DP, AVRCP, HFP, PBAP)
  • Bluetooth Version: V5
  • Microphone: Internal + External Microphone
  • ID3 Tag/Information (Artist, Album, Song): Yes
  • HFP Profile: HFP 1.6 (HD Voice)
• Tuner:
  • DAB: Yes
  • AM/FM (# of Presets): AM 12 / FM 18
  • FM Frequency Span (MHz): 87.5–108.0MHz (0.05MHz Step)
  • AM Frequency Span (KHz): 522–1710KHz (9KHz Step)
  • RDS: Yes
• RCA Preamp Outputs:
  • RCA Preamp Output: 4V, 5 Channel – 3 Pair (Front / Rear / Subwoofer)
  • Subwoofer Level Control: Yes
  • Preamp Voltage: 4V p-p
• Tone Control:
  • 13-Band EQ: 32/63/125/250/500/1K/2K/4K/8K/10K/12K/14K/16K
  • Loudness: Yes
  • LPF – Frequencies (Sub): Yes
  • Preset EQs: 6+2 Custom
  • Time Alignment: Yes
• Other Features:
  • Steering Wheel Control: Yes, with Aerpro SWC Adaptor
  • OSD Language: English
  • LED Colour (Buttons / Keys): 6-Colour Options (Red, Yellow, Green, Blue, Purple, White)
• Inclusions:
  • 10" Fixed Headunit (Trapezoid)
  • Mounting Hardware Screws
  • Wiring Harness with ISO Connection
  • AV, USB and Camera Harnesses
  • DAB Antenna
  • 3 Wire Learning SWC Lead
  • External Microphone with Mount
  • GPS Antenna with Adhesive Pad
  • QR Digital Manual Leaflet

Camera Specifications:

• Inclusions:
  • Surface Mount Camera (wired)
  • 6m of Video Cable (RCA) with in-line Reverse Trigger
• Mount Type: Surface Mount
• Camera Type: Front, Rear Or Reverse
• Lens Angle: 110 Degree

IMPORTANT INFORMATION:

• Head Unit Upgrade Kits can vary between vehicle models, please use the Aerpro What Fits Your Car Guide to find the correct parts.
• This kit includes an Infodaptor Interface which allows vehicle information to be displayed & accessed on the aftermarket head unit, retains steering wheel controls, retains parking tones & amplified system. The Interface connects to the rear camera input on the aftermarket head unit and the output for this kit will be low resolution.
• Only suits vehicles with MIB-PQ unit from factory.
• (*) Due to the size of the head unit, please be aware in Tiguan (2015-2016) vehicles the kit partially covers hazard button.
• Ignition Stabiliser may be required for stop-start models (Aerpro APIGNSTB, not included).
• Camera retention adaptor required to retain factory camera (Aerpro APVVW03, not included).
• May need to remove fuse from factory Bluetooth module for phone button to work.

Vehicles known to work with this product

• Volkswagen Beetle 2012-
• Volkswagen Tiguan 2015-2016
• Volkswagen Transporter T6 2016-2019
